This product is made of polytetrafluoroethylene dispersion resin through paste extrusion, calendering and drying. It can be used in the range of -150℃~260℃.

Applications:

Control cable
Coaxial cable
Thermocouple wire
Commercial and military aircraft wire

Benefits:

High dielectric strength
Outstanding thermal and chemical resistance
High temperature of operation
All colors are RoHS, REACH

Index:

Content	Index	Tolerance	Criteria	Remark
Density（g/cm3）	1.2-1.8	±0.05	Calculated	Customer Requirements
Tensile（Mpa)	≥20		ISO527
Elongation at break（%）	≥100		ISO527
Thickness(mm）	0.051,0.076,0.102,0.127,0.152,0.203,0.254	±0.005		Customer Requirements
width (mm)	3-15	±0.2		Customer Requirements
	>15	±0.3		Customer Requirements
Dielectric strength	≥30Kv/mm
Color	Natural,Red,Yellow,Blue,Green, White,Black,Pink,Purple,Orange,Gary,Brown			Customer Requirements
